6.0 Powerstroke Dual Alternator Belt Diagram

If you’re looking for a 6.0 Powerstroke dual alternator belt diagram, you’ve come to the right place. Here at AutoZone, we have all the information and parts you need to keep your truck running like new. With our easy-to-use online search tools, you can find the right parts for your truck in no time.

If you have a 6.0 Powerstroke and are looking for a dual alternator belt diagram, look no further! This helpful guide will show you exactly what you need to know in order to change your own belts. First, let’s take a look at what exactly the dual alternator system is and how it works.

The dual alternator system consists of two alternators that work together to charge the battery. One alternator charges the battery while the engine is running, and the other kicks in when the engine is off or idling. This ensures that your battery always has enough power to start your truck, even if it’s been sitting for awhile.

Now that we know how the system works, let’s take a look at the belt diagram. As you can see in the diagram, there are two main belts that run from the front of the engine to each respective alternator. There is also a small tensioner pulley located near each belt.

In order to change your belts, simply loosen and remove the old ones using a socket wrench. Then thread on the new belts (making sure they’re tight), and re-attach all of the pulleys using your socket wrench. That’s it!

You should now have fresh, new belts powering your dual alternators.

6.0 Powerstroke Dual Alternator Belt Diagram

Credit: www.ford-trucks.com

How Do You Remove the Belt on a 6.0 Powerstroke?

There are a few different ways that you can remove the belt on a 6.0 Powerstroke, but the most common method is by using a ratchet and socket. First, you will need to locate the tensioner pulley. This is usually located near the front of the engine, and it will have a square hole in the center.

Once you have found the tensioner pulley, insert the ratchet into the square hole and turn it counterclockwise. This will release the tension on the belt and allow you to remove it from the engine.

Why Do Diesel Trucks Have 2 Alternators?

Diesel trucks have two alternators because they need to generate a lot of power to run all the accessories in the truck, plus they need to be able to recharge the battery quickly. Having two alternators allows the truck to do both of these things more efficiently.

How Do You Tension an Auxiliary Belt?

Assuming you are referring to a serpentine belt: The first step is to locate the adjustment pulley. This is usually located at the furthest point of the engine from the crankshaft.

There may be more than one adjustment pulley, so consult your vehicle’s manual to be sure you’re adjusting the correct one. Once you’ve located the correct adjustment pulley, use a socket and ratchet to loosen, but not remove, the tensioner bolt. This will allow you to rotate the tensioner clockwise with your hand.

As you rotate the tensioner, observe the slack in the belt. Continue rotating the tensioner until there is no slack in the belt, then tighten the tensioner bolt back down.

What Belt is the Alternator Connected To?

The alternator is typically connected to the engine’s crankshaft via a serpentine belt. The belt transfers rotational force from the crankshaft to the alternator, which then generates electricity to charge the battery and power the electrical system.

2004 F350 6.0 Dual Alternator and Dual Tensioner replacement

6.0 Powerstroke Dual Alternator Bracket

If you’re looking to upgrade your 6.0 Powerstroke’s charging system, then a dual alternator bracket is a great option. This type of bracket allows you to install two alternators, which can provide more power and reliability than a single unit. There are a few things to keep in mind when choosing a dual alternator bracket for your 6.0 Powerstroke.

First, make sure that the bracket is compatible with your engine’s specific year and model. Second, take into account the type of alternators you’ll be using – there are brackets available for both factory and aftermarket units. Lastly, consider the overall cost of the kit – some brackets are more expensive than others due to their materials or construction.

Installing a dual alternator bracket on your 6.0 Powerstroke is relatively simple, but it’s always best to consult with a professional mechanic or installer before starting any work on your engine. With the right tools and knowledge, most people can complete this installation in about an hour or two. If you’re looking to improve your 6.0 Powerstroke’s charging system performance, then installing a dual alternator bracket is definitely worth considering!


This blog post provides a diagram of the dual alternator belt for the 6.0 Powerstroke engine. It shows how the two alternators are connected by a belt and how they work together to provide power to the engine.
